Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Sunivision/OEM/ HSX
  • Model Number: AP-F147-H51-C
  • Type: HD Coaxial Camera
  • Style: Bullet Camera
  • Sensor: CMOS
  • Technology: Infrared
  • Special Features: Waterproof / Weatherproof
  • VIDEO INPUT (BNC): 4 in 1
  • RECORD: 4*1080N:30fps/ch
  • PLAYBACK: 1*720P:30fps/ch
  • VIDEO OUTPUT: VGA HDMI
  • Image Resolution: 720p
  • Pixels: 1M Pixels
  • Infrared LED: F5X24PCS
  • Weatherproof Housing: YES, IP66
  • Focus Length: Board Lens 2.8mm/M12 F2.0
  • Warranty: 2 year warranty

Packaging & Delivery

Packaging Details Neutral packing for security camera system
(New model wholesale OEM 5MP AHD TVI CVI CVBS metal bullet camera 36pcs IR leds cctv camera system home security)
Delivery Time Sample order 2-7days, Formal order 7-15days

New model wholesale OEM 5MP AHD TVI CVI CVBS metal bullet camera 36pcs IR leds cctv camera system home security

Key Features

Feature:

(1)  AHD/TVI  5MP, H8538M+IMX326

(2)  High sensitivity in the dark environment, 0.1lux / F2.0, 0 lux(IR ON)

(3)  Smart Light Control to avoid over-exposure

(4)  Day and night features for 24-hour surveillance

(5)  IR distance: up to 30 meters with 36IR LEDs

(6)  IP66, suitable for outdoor use

(7)  Cable inside bracket, better waterproof

(8)  500m transmit

SPECIFICATION:

MODEL

AP-F147-H51-C

Image Device

FH8538M+IMX326

TV Format

PAL/NTSC

Number of Pixel

5MP, 2592*1944

Resolution

5MP

Sync.System

Internal

IR LED

36led

IR Effective Range

UP to 30 meters

Minimum Illumination

0LUX(IR ON)

LEN

f3.6MM/6MM (F2.0)

IP Rating

IP66

AGC

AUTO

S/N Ratio

≥48dB

Smart Light Control

YES

Gain Control

Auto

White Balance

Auto(2500°K~9500°K)

Electronic Shutter

Auto E Shutter:1/60(1/50)~1/100000 Sec(PAL)

1/60~-1/120,000 Sec(NTSC)

Back light Compensation

AUTO

Video Output

1.0Vp-p composite 75ohm

Power Consumption

350mA

Power Supply

DC12V

Operation Temp

-10°C~+50°C

Len option
